Description
Supermicro X11SSL-F: Reliable Micro-ATX Server Motherboard
The Supermicro X11SSL-F motherboard is designed for entry-level server platforms, offering a robust and cost-effective solution. It supports Intel Xeon E3-1200 v5, 6th-Gen Core i3, Pentium, or Celeron processors in an LGA 1151 (H4) socket, ensuring powerful performance for your server needs.
Key Features:
- Processor Support: Compatible with Intel Xeon E3-1200 v5, 6th-Gen Core i3, Pentium, and Celeron processors
- Chipset: Intel C232 chipset for enhanced reliability and performance
- Memory: Supports DDR4 memory for faster data processing
- Storage: Equipped with SATA 3.0 for high-speed storage solutions
- Security: Includes Intel Node Manager and Trusted Platform Module (TPM) for advanced security features
- Form Factor: Micro-ATX form factor for compact server builds
This motherboard is optimized for entry-level server platforms, providing a balance of performance and cost-effectiveness. The Intel C232 chipset ensures reliable operation, while the support for DDR4 memory and SATA 3.0 enables fast data processing and storage. With the inclusion of Intel Node Manager and TPM, you get enhanced security features to protect your server infrastructure.
Ideal for businesses looking for a dependable and affordable server motherboard, the Supermicro X11SSL-F is a great choice. Its compact Micro-ATX form factor makes it perfect for small server builds, while its robust feature set ensures it can handle demanding workloads.
Additional information
| Weight | 2.03 lbs |
|---|---|
| Dimensions | 11.3 × 10.8 × 2.2 in |
| Product Type | Motherboard – micro ATX |
| Storage Interfaces | SATA-600 -connectors: 6 x 7pin Serial ATA – 6 devices – RAID 0 / RAID 1 / RAID 10 / RAID 5 |
| Depth | 9.6 in |
| Width | 9.6 in |
| Compliant Standards | Plug and Play, RoHS |
| Software Included | SuperDoctor 5 |
| Hardware Features | Diagnostic LEDs, chassis intrusion detection, WatchDog Timer |
| Sleep / Wake Up | Keyboard wake up, RTC (real-time clock) wake up |
| Hardware Monitoring | CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU overheating protection, CPU core voltage |
| BIOS Features | APM 1.2 support, flash virus protection, power failure recovery (AC loss resume), DMI 2.3 support, UEFI BIOS, ACPI 4.0 support, SMBIOS 2.7.1 support, IPMI 2.0 support |
| BIOS Type | AMI |
| Internal Interfaces | 2 x USB 3.0 – header<br />1 x USB 3.0 – Type A<br />4 x USB 2.0 – header |
| Interfaces | 2 x LAN (Gigabit Ethernet)<br />2 x USB 2.0<br />2 x USB 3.0<br />1 x VGA<br />1 x serial<br />1 x management |
| Expansion Slots | 1 x CPU<br />4 x DIMM 288-pin (1.2 V)<br />1 x PCIe 3.0 x16 (x8 mode)<br />1 x PCIe 3.0 x8 (x4 mode)<br />1 x PCIe 3.0 x8 |
| Chipset Type | Intel C232 |
| Network Interfaces | 2 x Gigabit Ethernet |
| Network Controller | Intel I210-AT |
| Graphics Controller | ASPEED AST2400 |
| Registered or Buffered | Unbuffered |
| Supported RAM Integrity Check | ECC |
| Bus Clock | 1600 MHz, 1866 MHz, 2133 MHz |
| Technology | DDR4 |
| Max Size | 64 GB |
| Compatible Processors | Pentium, Celeron, Core i3, Xeon E3-1200 v5 series (Maximum TDP 80 Watt) |
| Max Processors Qty | 1 |
| Processor Socket | LGA1151 Socket |
| Service & Support | Limited warranty – parts – 1 year<br />Limited warranty – labor – 3 years |
